虚拟机初始化

初始化配置

如下配置非特定明确说明都是在root用户下操作.

网卡配置

修改网卡配置为静态网卡

先验证这个是否是主机IP 是的化可以直接执行如下脚本修改

1
ip addr | grep inet | grep brd |awk  '{split($2 ,attr_2 , "/") ;print attr_2[1]}'
1
2
3
[root@lqz-test-demo ~]# ip addr | grep inet | grep brd |awk  '{split($2 ,attr_2 , "/") ;print attr_2[1]}'
192.168.16.130
[root@lqz-test-demo ~]#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
IPADDR=$(ip addr | grep inet | grep brd |awk  '{split($2 ,attr_2 , "/") ;print attr_2[1]}')
GATEWAY=$(ip route | grep 'default via' |awk '{print $3}')
cp /etc/sysconfig/network-scripts/ifcfg-ens33 /etc/sysconfig/network-scripts/bak_ifcfg-ens33_$(date +%Y%m%d%H%M%S)
cp /etc/sysconfig/network-scripts/ifcfg-ens33 /etc/sysconfig/network-scripts/bak_ifcfg-ens33
awk  -v SYH='"'  -v IPADDR="${IPADDR}"  -v GATEWAY="${GATEWAY}"  -v NETMASK="${NETMASK}"  'BEGIN{FS=OFS="="}
 ! ( $1 == "IPADDR" || $1 == "GATEWAY" || $1 == "NETMASK" || $1 == "DNS1" || $1 == "DNS2" ) {
if ($1 == "BOOTPROTO") {
   $2 = SYH "static" SYH
}
if ($1 == "ONBOOT") {
   $2 = SYH "yes" SYH
}
print $1,$2
}END{
 print "IPADDR=" IPADDR
 print "GATEWAY=" GATEWAY
 print "NETMASK=" "255.255.255.0"
 print "DNS1=" "114.114.114.114"
 print "DNS2=" "8.8.8.8"
}' /etc/sysconfig/network-scripts/bak_ifcfg-ens33> /etc/sysconfig/network-scripts/ifcfg-ens33
reboot

重启后发现还会有一个动态IP
需要关闭NetworkManager服务,并重启network服务

1
2
3
systemctl stop  NetworkManager
systemctl disable  NetworkManager
systemctl restart network
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
[root@lqz-test-demo network-scripts]# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000
    link/ether 00:0c:29:00:27:bc brd ff:ff:ff:ff:ff:ff
    inet 192.168.16.130/24 brd 192.168.16.255 scope global noprefixroute ens33
       valid_lft forever preferred_lft forever
    inet 192.168.16.131/24 brd 192.168.16.255 scope global secondary dynamic ens33
       valid_lft 1704sec preferred_lft 1704sec
    inet6 fe80::8774:3783:156b:5f1a/64 scope link noprefixroute
       valid_lft forever preferred_lft forever
[root@lqz-test-demo network-scripts]# systemctl status NetworkManager
● NetworkManager.service - Network Manager
   Loaded: loaded (/usr/lib/systemd/system/NetworkManager.service; enabled; vendor preset: enabled)
   Active: active (running) since 二 2023-11-21 23:17:28 CST; 2min 29s ago
     Docs: man:NetworkManager(8)
 Main PID: 706 (NetworkManager)
   CGroup: /system.slice/NetworkManager.service
           └─706 /usr/sbin/NetworkManager --no-daemon

11月 21 23:17:28 lqz-test-demo NetworkManager[706]: <warn>  [1700579848.7337] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_bak due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:28 lqz-test-demo NetworkManager[706]: <warn>  [1700579848.7344] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_20231121231146 due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:28 lqz-test-demo NetworkManager[706]: <warn>  [1700579848.8725] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_20231121231146 due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:28 lqz-test-demo NetworkManager[706]: <warn>  [1700579848.8883] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_20231121231146 due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:30 lqz-test-demo NetworkManager[706]: <info>  [1700579850.9833] manager: NetworkManager state is now CONNECTED_SITE
11月 21 23:17:30 lqz-test-demo NetworkManager[706]: <info>  [1700579850.9833] policy: set 'ens33' (ens33) as default for IPv4 routing and DNS
11月 21 23:17:31 lqz-test-demo NetworkManager[706]: <warn>  [1700579851.0195] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_20231121231146 due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:31 lqz-test-demo NetworkManager[706]: <warn>  [1700579851.0489] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_20231121231146 due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:31 lqz-test-demo NetworkManager[706]: <warn>  [1700579851.0881] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_bak due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
11月 21 23:17:31 lqz-test-demo NetworkManager[706]: <warn>  [1700579851.1040] ifcfg-rh: cannot load /etc/sysconfig/network-scripts/ifcfg-ens33_bak due to conflicting UUID for /etc/sysconfig/network-scripts/ifcfg-ens33 (14449c29-9b36-4b3e-9182-79c6b5740780,"ens33")
[root@lqz-test-demo network-scripts]# systemctl status network
● network.service - LSB: Bring up/down networking
   Loaded: loaded (/etc/rc.d/init.d/network; bad; vendor preset: disabled)
   Active: active (running) since 二 2023-11-21 23:19:04 CST; 58s ago
     Docs: man:systemd-sysv-generator(8)
  Process: 1494 ExecStart=/etc/rc.d/init.d/network start (code=exited, status=0/SUCCESS)
   CGroup: /system.slice/network.service
           └─1081 /sbin/dhclient -1 -q -lf /var/lib/dhclient/dhclient--ens33.lease -pf /var/run/dhclient-ens33.pid -H lqz-test-demo ens33

11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo network[1494]: RTNETLINK answers: File exists
11月 21 23:19:04 lqz-test-demo systemd[1]: Started LSB: Bring up/down networking.
[root@lqz-test-demo network-scripts]# systemctl stop  NetworkManager
[root@lqz-test-demo network-scripts]# systemctl disable  NetworkManager
Removed symlink /etc/systemd/system/multi-user.target.wants/NetworkManager.service.
Removed symlink /etc/systemd/system/dbus-org.freedesktop.nm-dispatcher.service.
Removed symlink /etc/systemd/system/network-online.target.wants/NetworkManager-wait-online.service.
[root@lqz-test-demo network-scripts]# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000
    link/ether 00:0c:29:00:27:bc brd ff:ff:ff:ff:ff:ff
    inet 192.168.16.130/24 brd 192.168.16.255 scope global noprefixroute ens33
       valid_lft forever preferred_lft forever
    inet 192.168.16.131/24 brd 192.168.16.255 scope global secondary dynamic ens33
       valid_lft 1624sec preferred_lft 1624sec
    inet6 fe80::8774:3783:156b:5f1a/64 scope link noprefixroute
       valid_lft forever preferred_lft forever
[root@lqz-test-demo network-scripts]# systemctl restart network
[root@lqz-test-demo network-scripts]# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000
    link/ether 00:0c:29:00:27:bc brd ff:ff:ff:ff:ff:ff
    inet 192.168.16.130/24 brd 192.168.16.255 scope global ens33
       valid_lft forever preferred_lft forever
    inet6 fe80::20c:29ff:fe00:27bc/64 scope link
       valid_lft forever preferred_lft forever
[root@lqz-test-demo network-scripts]#

至此ip修改完成

  • 如果路由策略不小心修改错误缺少了.可以使用如下方法修复
    1
    ip route add default via 192.168.16.2

hostname修改(根据集群规划选择性修改定义)

1
hostnamectl set-hostname master-tool

hosts文件修改(根据集群规划选择性修改定义)

1
2
3
4
5
6
7
8
9
cat >> /etc/hosts <<HOSTS
192.168.16.100  tools
192.168.16.101  master-01
192.168.16.102  master-02
192.168.16.103  master-03
192.168.16.201  node-01
192.168.16.202  node-02
192.168.16.203  node-03
HOSTS

应用用户配置

安装时已经创建了userapp用户,测试环境我就不再创建了(并且userapp具有sudo权限),

如果需要创建可以参考如下命令

1
2
3
4
# 创建用户组
groupadd -g 3000 {groupname}
# 创建用户
useradd -u 3000 -g 3000 -d /home/{username}  -s /bin/bash -m  {username}

目录配置

目录规划

1
2
3
4
5
6
7
8
9
10
11
12
# /data 为数据盘.
# 如果条件充裕也可以将数据类文件做动静分离,静态类目录放nfs上,则不用不数那么多软件包副本. 动态类防止在各自的本地盘.
# 动静分离类盘要提前规划,需要提前了解哪些路径是可以叠加复用,难度较大,目前暂不考虑.所有节点都放在本地盘
mkdir -p /data/app/        # 存放应用以及实例相关数据
mkdir -p /data/pkg/        # 存放各个应用的安装包
mkdir -p /data/docker/     # 若用到docker该目录存放docker相关的组件
mkdir -p /data/k8s/        # 若用到看k8s该目录存放k8s相关的组件
mkdir -p /data/log/        # 通用日志目录
mkdir -p /data/tmp/        # 通用临时文件目录
mkdir -p /data/bak/        # 通用备份目录
mkdir -p /data/DS/         # 通用DataStone存储目录
chown -R userapp:userapp /data
  • 如果有其他lv /lg 等相关配置自行规划,这里不再赘述

集群ssh免密钥配置

这里配置两组
第一组, 本机root用户转其他主机root用户

在root用户下执行

1
ssh-keygen -t rsa

将公钥提交到本机

1
2
3
4
ssh-copy-id root@192.168.16.130
# 输入密码
# 执行完成后检查是否新生成文件authorized_keys
cat ~/.ssh/authorized_keys

手动删除末尾的” root@lqz-test-demo” 信息

删除后

第二组, 本机userapp用户跳转其他主机userapp用户

在userapp用户下执行

1
ssh-keygen -t rsa

将公钥提交到本机

1
2
3
4
ssh-copy-id userapp@192.168.16.130
# 输入密码
# 执行完成后检查是否新生成文件authorized_keys
cat ~/.ssh/authorized_keys

删除后

防火墙关闭 & 关闭 SELINUX

1
2
3
4
systemctl stop firewalld
systemctl disable firewalld
swapoff -a && sed -i '/ swap / s/^\(.*\)$/#\1/g' /etc/fstab
setenforce 0 && sed -i 's/^SELINUX=.*/SELINUX=disabled/' /etc/selinux/config

yum源替换成国内源

1
2
3
4
5
6
yum install wget  ca-certificates -y
mkdir -p /etc/yum.repos.d/repo_bak
mv  /etc/yum.repos.d/*repo  /etc/yum.repos.d/repo_bak/
wget -O /etc/yum.repos.d/CentOS-Base.repo http://mirrors.163.com/.help/CentOS7-Base-163.repo
yum clean all
yum makecache

设置防火墙为 Iptables 并设置空规则

1
2
3
4
5
yum -y install iptables-services
systemctl start iptables
systemctl enable iptables
iptables -F
service iptables save

常用组件安装

1
yum install -y net-tools lrzsz  gzip curl vim  git ntp

时钟同步

1
2
3
4
# 设置系统时区为 中国/上海
timedatectl set-timezone Asia/Shanghai
# 将当前的 UTC 时间写入硬件时钟
timedatectl set-local-rtc 0

修改同步配置文件信息增加如下信息 /etc/ntp.conf

1
2
3
4
5
6
7
# 上游通过阿里云始终服务进行同步
server ntp1.aliyun.com prefer
server ntp2.aliyun.com
# 下游可提共ntp服务如果上有不可用则用自己作为时钟源
server 127.127.1.0 iburst
fudge 127.127.1.0 stratum 10
restrict 192.168.16.0 mask 255.255.255.0 nomodify notrap


启动始终同步并检查

1
2
service ntpd start
chkconfig ntpd on


重启依赖于系统时间的服务 (多余步骤,仅供参考,后续demo服务器会关闭重启)

1
2
systemctl restart rsyslog
systemctl restart crond

关闭系统不需要服务

1
2
systemctl stop postfix
systemctl disable postfix

应用安装

如下默认使用用用账号 userapp

jdk

自行下载jdk1.8安装包,并上传到环境

因为已经安装过lrzsz了,

进入目录后,可以直接从文件夹中拖拽压缩包到xshell中.
配置应用目录,并配置环境变量

  • (版本号我进行了保留,因为后续可能会安装多个版本的jdk)
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    # 创建应用目录并解压
    mkdir -p /data/app/jdk
    tar -xvzf /data/pkg/jdk-8u212-linux-x64.tar.gz -C /data/app/jdk
    ls -ld /data/app/jdk/*

    # 配置环境变量
    cat >> ~/.bashrc <<JDKENV

    ## jdk env
    export JAVA_HOME=/data/app/jdk/jdk1.8.0_212
    export PATH=\${JAVA_HOME}/bin:$PATH
    export CLASSPATH=.:\${JAVA_HOME}/lib/dt.jar:\${JAVA_HOME}/lib/tools.jar
    JDKENV
    . ~/.bashrc

    # 验证java
    cat ~/.bashrc

    java -version
    jdk环境安装完成

conda环境

安装miniconda

1
2
3
4
5
# 下载安装包
wget https://repo.anaconda.com/miniconda/Miniconda3-latest-Linux-x86_64.sh -O /data/pkg/miniconda.sh
# 安装
chmod +x /data/pkg/miniconda.sh
/data/pkg/miniconda.sh

具体选项可以参考如下信息

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
# 该位置直接回车跳过
In order to continue the installation process, please review the license
agreement.
Please, press ENTER to continue
>>>
....
....
The following packages listed on https://www.anaconda.com/cryptography are included in the Repository accessible through Miniconda that relate to cryptography.

Last updated March 21, 2022


Do you accept the license terms? [yes|no]
>>> yes
....
....

[/home/userapp/miniconda3] >>> /data/app/miniconda3
PREFIX=/data/app/miniconda3
Unpacking payload ...
...
...
conda config --set auto_activate_base false

You can undo this by running `conda init --reverse $SHELL`? [yes|no]
[no] >>> yes
no change     /data/app/miniconda3/condabin/conda
no change     /data/app/miniconda3/bin/conda
no change     /data/app/miniconda3/bin/conda-env
no change     /data/app/miniconda3/bin/activate
no change     /data/app/miniconda3/bin/deactivate
no change     /data/app/miniconda3/etc/profile.d/conda.sh
no change     /data/app/miniconda3/etc/fish/conf.d/conda.fish
no change     /data/app/miniconda3/shell/condabin/Conda.psm1
no change     /data/app/miniconda3/shell/condabin/conda-hook.ps1
no change     /data/app/miniconda3/lib/python3.11/site-packages/xontrib/conda.xsh
no change     /data/app/miniconda3/etc/profile.d/conda.csh
modified      /home/userapp/.bashrc

==> For changes to take effect, close and re-open your current shell. <==

Thank you for installing Miniconda3!
  • (选择性配置,如果不理解可以不做变更)修改conda环境激活为手工.
    将刚才自动写入~/.bashrc中的conda相关的脚本,重新写入到.bash_conda

    以后在脚本中使用可以引用该环境变量选择性手动激活
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    cat > ~/.bash_conda <<CONDAENV
    # >>> conda initialize >>>
    # !! Contents within this block are managed by 'conda init' !!
    __conda_setup="\$('/data/app/miniconda3/bin/conda' 'shell.bash' 'hook' 2> /dev/null)"
    if [ $? -eq 0 ]; then
        eval "$__conda_setup"
    else
        if [ -f "/data/app/miniconda3/etc/profile.d/conda.sh" ]; then
            . "/data/app/miniconda3/etc/profile.d/conda.sh"
        else
            export PATH="/data/app/miniconda3/bin:$PATH"
        fi
    fi
    unset __conda_setup
    # <<< conda initialize <<<
    CONDAENV
    测试激活conda是否安装成功
    1
    conda activate base

配置conda国内清华源

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
# 生成配置文件
conda config --set show_channel_urls yes
# 配置清华源
cat > ~/.condarc<<CONDAREP
channels:
  - defaults
show_channel_urls: true
default_channels:
  - https://mirrors.tuna.tsinghua.edu.cn/anaconda/pkgs/main
  - https://mirrors.tuna.tsinghua.edu.cn/anaconda/pkgs/r
  - https://mirrors.tuna.tsinghua.edu.cn/anaconda/pkgs/msys2
custom_channels:
  conda-forge: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  msys2: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  bioconda: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  menpo: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  pytorch: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  pytorch-lts: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  simpleitk: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud
  deepmodeling: https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud/
CONDAREP
# 清理缓存
conda clean -i
# 测试配置是否成功
conda create -n mytest python=3.8.2

之后所作的配置是选择性的配置,可以选增性增加镜像点. 最好是自己知道自己需要什么之后在做配置,如果不知道,就默认不配置

制作快照


选择性配置

升级内核(centos7的自带版本的内核版本较低,如果要安装k8s可以升级内核)

rpm资源 可以选择最新的rpm包进行安装
centos7

1
yum install https://www.elrepo.org/elrepo-release-7.el7.elrepo.noarch.rpm

升级内核

1
yum --enablerepo=elrepo-kernel install -y kernel-lt


1
grep 'CentOS Linux' /boot/grub2/grub.cfg

可以查看已经安装成功
将高版本的内核设定为启动默认配置

1
grub2-set-default 'CentOS Linux (5.4.265-1.el7.elrepo.x86_64) 7 (Core)'

重启可以看到默认选择的是高版本的内核

1
reboot


1
uname -a
